RF316PXXB0 04 – UNIT, OPTIONAL

RF316PXXB0 04 – UNIT, OPTIONAL

Written by

in

RF316PXXB0 04 – UNIT, OPTIONAL

Products

PositionProduct
1Bracket, Mounting (2)
34396923 Whirlpool Broil Pan Set Gray Porcelain
4ELMNT-BAKE
5WP660579 Whirlpool Range Wall Oven Broil Element, 3000W, 240V
5Screw (2)
6WP112432 Whirlpool Nut Assembly
6WP8203546 Whirlpool Terminal Block
6Screw, (2) 10-16 x 1
7Clip, Ground Wire
7WPL 308498
8Bracket, Service
10Cover, Rear
11SCREW
11Cover, Service
12Rail R.H. (Includes Illus. 3)
12Rail L.H. (Includes Illus. 3)
13Glide, Front (2)
14WPL 308173
15WPL 308172
1716515 Whirlpool Clip
18Wire (14 Ga. 150 c Blue)
18Wire (14 Ga. 150 c Brown)
18Wire (14 Ga. 150 c Green)
18Block, Balance
18Wire, 25“ Roll (White 14 GA.)
18Wire (14 Ga. 150 c Orange)
18Wire (14 Ga. 150 c Yellow)
188212471 Whirlpool Oven Paint
18Leveler (Thinner) (2oz.)
18Rotisserie Kit
18Grease
18340184 Whirlpool Screw
181
18Wire (14 Ga. 200 c Brown)
1818 Ga. 80~c Rating (Red)
18Wire (12 Ga. 150 c Black)
18Enamel, Coffee (1 Qt. Uncut)
18242831 Whirlpool Oven Wire
18350930 Whirlpool White Spray Paint
18Platinum (Uncut)
18Enamal, Toast (1 Qt. Uncut)
18Paint, Spray (13 Oz.) (Platinum)
18Toast
18Golden Harvest (Uncut)
18Golden Harvest
1872113 Whirlpool Touch-Up Paint
1872110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
18Almond (Uncut)
18WP72107 Whirlpool Touchup
18799344 Whirlpool Refrigerator Paint
1872017 Whirlpool Appliance Touch-Up Paint White
18WPL 72112
18350942 Whirlpool Spray Paint
18W10355051 Whirlpool Cooktop Cleaner Affresh (10 Oz)
18Paint, Spray 13 Oz. (Avocado)
18paint, spray 13 oz. (coffee)
18Paint, Touch-Up 1/2 Oz. (Coffee)
1872109 Whirlpool Dacor Avocado Touch-Up Paint
18285006 Whirlpool Spray
18Wire, 25` Roll (Red 14 Ga.)
18Wire, 25` Roll (Black 14 Ga.)
18FOIL, ALUMINUM OVEN (18“ X 25 )
18WPW10208653 Whirlpool Insulation
18WPL 799832
18511873 Whirlpool Refrigerator Paint
18350956 Whirlpool Spray Assembly
