RF316PXXN2 04 – UNIT, OPTIONAL

RF316PXXN2 04 – UNIT, OPTIONAL

RF316PXXN2 04 – UNIT, OPTIONAL

Products

PositionProduct
1Bracket, Mounting (2)
34396923 Whirlpool Broil Pan Set Gray Porcelain
4ELMNT-BAKE
5Screw (2)
5WP660579 Whirlpool Range Wall Oven Broil Element, 3000W, 240V
6WP112432 Whirlpool Nut Assembly
6Screw, (2) 10-16 x 1
6WP8203546 Whirlpool Terminal Block
7WPL 308498
7Clip, Ground Wire
8Bracket, Service
10Cover, Rear
11SCREW
11Cover, Service
12Rail L.H. (Includes Illus. 3)
12Rail R.H. (Includes Illus. 3)
13Glide, Front (2)
14WPL 308173
15WPL 308172
1716515 Whirlpool Clip
18Insulation, Wrap
188212471 Whirlpool Oven Paint
18Leveler (Thinner) (2oz.)
18Golden Harvest
18Golden Harvest (Uncut)
18Enamel, Coffee (1 Qt. Uncut)
181
18Wire (14 Ga. 200 c Brown)
1818 Ga. 80~c Rating (Red)
18Wire (12 Ga. 150 c Black)
18Grease
1872113 Whirlpool Touch-Up Paint
188273888A Whirlpool Range Oven Anchor Anti-Tip Bracket Kit
18Block, Balance
18350956 Whirlpool Spray Assembly
1872017 Whirlpool Appliance Touch-Up Paint White
18799344 Whirlpool Refrigerator Paint
18WP72107 Whirlpool Touchup
18Almond (Uncut)
1872110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
18350930 Whirlpool White Spray Paint
18340184 Whirlpool Screw
18Wire (14 Ga. 150 c Yellow)
18Toast
18Wire (14 Ga. 150 c Orange)
18paint, spray 13 oz. (coffee)
18Paint, Touch-Up 1/2 Oz. (Coffee)
1872109 Whirlpool Dacor Avocado Touch-Up Paint
18285006 Whirlpool Spray
18511873 Whirlpool Refrigerator Paint
18Wire, 25` Roll (Red 14 Ga.)
18Wire, 25` Roll (Black 14 Ga.)
18WPL 799832
18FOIL, ALUMINUM OVEN (18“ X 25 )
18Paint, Spray 13 Oz. (Avocado)
18W10355051 Whirlpool Cooktop Cleaner Affresh (10 Oz)
18350942 Whirlpool Spray Paint
18Wire, 25“ Roll (White 14 GA.)
18Wire (14 Ga. 150 c Green)
18Wire (14 Ga. 150 c Brown)
18Wire (14 Ga. 150 c Blue)
18242831 Whirlpool Oven Wire
18Paint, Spray (13 Oz.) (Platinum)
18Enamal, Toast (1 Qt. Uncut)
18Platinum (Uncut)
18WPL 72112
18WPW10208653 Whirlpool Insulation
