RF325PXEZ0 05 – DOOR, LIT/OPTIONAL

RF325PXEZ0 05 – DOOR, LIT/OPTIONAL

Written by

in

RF325PXEZ0 05 – DOOR, LIT/OPTIONAL

Products

Position	Product
	W11396691 Whirlpool Element Receptacle and Wire Kit
	3184020 Whirlpool Oven Wire
	Harness, Wire (Door Switch)
	Literature (Installation, Instructions (Template))
	WP3196154 Whirlpool Screw Assembly
	3400964 Whirlpool Oven Clip
	WPL LIT3195944
	Clip, Ground Wire
	WPL LIT3196274
	WPL 3195951
	WPL LIT3196106
1	WPW10016370 Whirlpool Door Trim
1	Trim, Top (Almond)
2	WP179051 Whirlpool Screw
3	Handle, Door (Almond)
3	WPW10202216 Whirlpool Door Handle
4	Liner, Door
5	Insulation, Door
6	WP9758164 Whirlpool Door Glass
7	9761500 Whirlpool Oven Retainer
8	Hinge, Door (2)
9	Glass, Outer (Almond)
9	WP9762476 Whirlpool Door Glass
11	W10491985 Whirlpool Screw
12	8184859 Whirlpool Range Oven Door Trim Kit (2 Sides, 1 Bottom)
12	8184860 Whirlpool Oven Door Trim
15	WP3196164 Whirlpool Screw
16	Plug, Door
17	Clip, Glass (4)
18	18 Ga. 80~c Rating (Red)
18	Wire (14 Ga. 150 c Yellow)
18	Wire (12 Ga. 150 c Black)
18	Golden Harvest
18	Wire (14 Ga. 200 c Brown)
18	1
18	8212471 Whirlpool Oven Paint
18	Grease
18	8273888A Whirlpool Range Oven Anchor Anti-Tip Bracket Kit
18	Wire (14 Ga. 150 c Orange)
18	Wire (14 Ga. 150 c Green)
18	350942 Whirlpool Spray Paint
18	WPL 72112
18	Platinum (Uncut)
18	Enamal, Toast (1 Qt. Uncut)
18	Paint, Spray (13 Oz.) (Platinum)
18	Toast
18	Golden Harvest (Uncut)
18	72113 Whirlpool Touch-Up Paint
18	72110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
18	Almond (Uncut)
18	WP72107 Whirlpool Touchup
18	799344 Whirlpool Refrigerator Paint
18	72017 Whirlpool Appliance Touch-Up Paint White
18	350956 Whirlpool Spray Assembly
18	511873 Whirlpool Refrigerator Paint
18	WPL 799832
18	238614 Whirlpool Bumper Hinge
18	Wire (14 Ga. 150 c Brown)
18	Wire (14 Ga. 150 c Blue)
18	242831 Whirlpool Oven Wire
18	W10355051 Whirlpool Cooktop Cleaner Affresh (10 Oz)
18	Paint, Spray 13 Oz. (Avocado)
18	paint, spray 13 oz. (coffee)
18	Paint, Touch-Up 1/2 Oz. (Coffee)
18	72109 Whirlpool Dacor Avocado Touch-Up Paint
18	285006 Whirlpool Spray
18	Wire, 25“ Roll (White 14 GA.)
18	Wire, 25` Roll (Red 14 Ga.)
18	Wire, 25` Roll (Black 14 Ga.)
18	FOIL, ALUMINUM OVEN (18“ X 25 )
18	WPW10208653 Whirlpool Insulation
18	350930 Whirlpool White Spray Paint
