RF377PXVN0 03 – CONTROL PANEL

Products

Position	Product
1	End Trim L.H.
1	Washer
1	Washer
2	End Cap L.H.
2	End Cap R.H.
2	Screw,
3	Motor, Timer
4	Lens, Amber
5	Timer, Clock (Includes No.6)
6	Glass, Timer
7	Control, Panel
8	SWITCH-INF
8	WP3148952 Whirlpool Oven Infinite Switch
9	98005642 Whirlpool Clip
9	Adapter, Terminal
9	WP486579 Whirlpool Air Conditioner Screw
9	Switch, Selector (5 Position)
10	WP313808 Whirlpool Screw
10	Thermostat, Oven
11	Light, Indicator (Surface Unit (2))
11	Indicator Light (1)
11	Light, Indicator (250V)
12	WP4314961 Whirlpool Lite Switch
13	Knob, Control (4)
14	Knob, Control (2)
15	Harness-Conduit Asm.
15	SCREW
16	Spring (3)
16	WP3169181 Whirlpool Knob
17	Shield (2)
17	WP965173 Whirlpool Dishwasher Screw
18	KNOB, CONTROL
18	WP688805 Whirlpool Spring Clip
