RF385PCVN0 05 – CONTROL PANELadmin2025-04-26T12:48:38+00:00RF385PCVN0 05 – CONTROL PANEL
Products
| Position | Product |
|---|
| 1 | Washer |
| 1 | Washer |
| 1 | End Trim L.H. |
| 2 | End Cap R.H. |
| 2 | End Cap L.H. |
| 2 | Screw, |
| 3 | Bracket, Timer (2) |
| 5 | Lens, Amber |
| 6 | Sleeve-Igniter Wire (Lt. or Rt.) |
| 10 | Timer |
| 12 | Glass, Timer |
| 16 | Control, Panel |
| 17 | WP3149400 Whirlpool Oven Infinite Switch |
| 17 | WP3148952 Whirlpool Oven Infinite Switch |
| 18 | Switch, Selector (5 Position) |
| 18 | WP486579 Whirlpool Air Conditioner Screw |
| 18 | Adapter, Terminal |
| 19 | Thermostat, Oven |
| 19 | WP313808 Whirlpool Screw |
| 21 | Light, Indicator (250V) |
| 21 | Light, Indicator (Surface Unit (2)) |
| 21 | Indicator Light (1) |
| 23 | WP4314961 Whirlpool Lite Switch |
| 24 | Knob, Control (4) |
| 25 | Knob, Control (2) |
| 26 | WP688805 Whirlpool Spring Clip |
| 27 | Harness-Conduit Asm. |
| 27 | SCREW |
| 28 | Knob, Bit Generator (Black) |
| 29 | WP965173 Whirlpool Dishwasher Screw |
| 29 | Shield (2) |
| 30 | KNOB, CONTROL |
