RF385PXVW0 04 – UNIT, LIT/OPTIONALadmin2025-04-26T12:48:58+00:00RF385PXVW0 04 – UNIT, LIT/OPTIONAL
Products
| Position | Product |
|---|
| WPL LIT3148614 |
| WPL LIT884345 |
| WPL LIT3148541 |
| WPL LIT313426 |
| WPL LIT313358 |
| 1 | Bracket, Mounting (2) |
| 2 | Rail R.H. (Includes Illus. 3) |
| 2 | Rail L.H. (Includes Illus. 3) |
| 3 | Glide, Front (2) |
| 4 | ELMNT-BAKE |
| 5 | Screw, 10-32 x 5/8 (4) |
| 5 | WP660579 Whirlpool Range Wall Oven Broil Element, 3000W, 240V |
| 6 | WP112432 Whirlpool Nut Assembly |
| 6 | WP8203546 Whirlpool Terminal Block |
| 6 | Screw, (2) 10-16 x 1 |
| 7 | WPL 308498 |
| 7 | Clip, Ground Wire |
| 8 | Bracket, Service |
| 10 | Cover, Rear |
| 11 | Cover, Service |
| 11 | SCREW |
| 13 | 4396923 Whirlpool Broil Pan Set Gray Porcelain |
| 14 | WPL 308173 |
| 15 | WPL 308172 |
| 17 | Screw, 10A x 1/2 (2) (Black) |
| 17 | WPL 311982 |
| 18 | Sensor, Temperature |
| 19 | 16515 Whirlpool Clip |
| 20 | Sw |
| 21 | Wire (12 Ga. 150 c Black) |
| 21 | Wire (14 Ga. 150 c Yellow) |
| 21 | Leveler (Thinner) (2oz.) |
| 21 | 8212471 Whirlpool Oven Paint |
| 21 | Wire (14 Ga. 150 c Orange) |
| 21 | Switch, Bake |
| 21 | Wire (14 Ga. 200 c Brown) |
| 21 | 350930 Whirlpool White Spray Paint |
| 21 | Grease |
| 21 | 1 |
| 21 | Enamel, Coffee (1 Qt. Uncut) |
| 21 | 18 Ga. 80~c Rating (Red) |
| 21 | Wire (14 Ga. 150 c Green) |
| 21 | WPL 72112 |
| 21 | Platinum (Uncut) |
| 21 | Enamal, Toast (1 Qt. Uncut) |
| 21 | Paint, Spray (13 Oz.) (Platinum) |
| 21 | Toast |
| 21 | Golden Harvest (Uncut) |
| 21 | Golden Harvest |
| 21 | 72113 Whirlpool Touch-Up Paint |
| 21 | 72110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz |
| 21 | Almond (Uncut) |
| 21 | WP72107 Whirlpool Touchup |
| 21 | 799344 Whirlpool Refrigerator Paint |
| 21 | 72017 Whirlpool Appliance Touch-Up Paint White |
| 21 | 350942 Whirlpool Spray Paint |
| 21 | 511873 Whirlpool Refrigerator Paint |
| 21 | Wire (14 Ga. 150 c Brown) |
| 21 | Wire (14 Ga. 150 c Blue) |
| 21 | WPL 314215 |
| 21 | paint, spray 13 oz. (coffee) |
| 21 | 242831 Whirlpool Oven Wire |
| 21 | Paint, Spray 13 Oz. (Avocado) |
| 21 | Paint, Touch-Up 1/2 Oz. (Coffee) |
| 21 | 72109 Whirlpool Dacor Avocado Touch-Up Paint |
| 21 | 285006 Whirlpool Spray |
| 21 | Wire, 25`` Roll (White 14 GA.) |
| 21 | Wire, 25` Roll (Red 14 Ga.) |
| 21 | Wire, 25` Roll (Black 14 Ga.) |
| 21 | WPL 799832 |
| 21 | 350956 Whirlpool Spray Assembly |
