RF387PXVF0 06 – OVEN (CONTINUED) , LITERATURE AND OPTIONAL

RF387PXVF0 06 – OVEN (CONTINUED) , LITERATURE AND OPTIONAL

RF387PXVF0 06 – OVEN (CONTINUED) , LITERATURE AND OPTIONAL

Products

PositionProduct
WPL LIT313358
WPL LIT3149775
WPL LIT3148542
Instructions, Installation
WPL LIT884347
511873 Whirlpool Refrigerator Paint
WPL LIT3149507
1Bracket, Mounting (2)
2Rail R.H. (Includes Illus. 3)
2Rail L.H. (Includes Illus. 3)
3Glide, Front (2)
4ELMNT-BAKE
5WP660579 Whirlpool Range Wall Oven Broil Element, 3000W, 240V
5Screw, 10-32 x 5/8 (4)
6WP112432 Whirlpool Nut Assembly
6Screw, (2) 10-16 x 1
6WP8203546 Whirlpool Terminal Block
7Clip, Ground Wire
7WPL 308498
8Bracket, Service
10Cover, Rear
11Cover, Service
134396923 Whirlpool Broil Pan Set Gray Porcelain
14WPL 308173
15WPL 308172
16WPL 311982
16Screw, 10A x 1/2 (2) (Black)
17SCREW
17Sensor, Heat
18Wire (12 Ga. 150 c Black)
188212471 Whirlpool Oven Paint
1818 Ga. 80~c Rating (Red)
18Wire (14 Ga. 200 c Brown)
18dressing, element
181
18Block, Balance
18Rotisserie Kit (RCK 81)
18Leveler (Thinner) (2oz.)
18Grease
18Enamel, Coffee (1 Qt. Uncut)
18Enamel, New Avocado (1 Qt. Uncut)
18340184 Whirlpool Screw
18Golden Harvest
18Wire (14 Ga. 150 c Yellow)
18Wire (14 Ga. 150 c Orange)
18WPL 72112
18Platinum (Uncut)
18Enamal, Toast (1 Qt. Uncut)
18Paint, Spray (13 Oz.) (Platinum)
18Toast
18Golden Harvest (Uncut)
1872113 Whirlpool Touch-Up Paint
1872110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
18Almond (Uncut)
18WP72107 Whirlpool Touchup
18799344 Whirlpool Refrigerator Paint
1872017 Whirlpool Appliance Touch-Up Paint White
18350956 Whirlpool Spray Assembly
18350942 Whirlpool Spray Paint
18WPL 799832
18WPW10208653 Whirlpool Insulation
18Wire (14 Ga. 150 c Green)
18Wire (14 Ga. 150 c Brown)
18Wire (14 Ga. 150 c Blue)
18242831 Whirlpool Oven Wire
18Paint, Spray 13 Oz. (Avocado)
18paint, spray 13 oz. (coffee)
18Paint, Touch-Up 1/2 Oz. (Coffee)
1872109 Whirlpool Dacor Avocado Touch-Up Paint
18285006 Whirlpool Spray
18Wire, 25“ Roll (White 14 GA.)
18Wire, 25` Roll (Red 14 Ga.)
18Wire, 25` Roll (Black 14 Ga.)
18FOIL, ALUMINUM OVEN (18“ X 25 )
18350930 Whirlpool White Spray Paint
