RF390PXWN0 06 – LITERATURE AND OPTIONAL

Products

Position	Product
	511873 Whirlpool Refrigerator Paint
	Screw (10-12 x .875)
1	Main Chassis (White)
1	Main Chassis (Almond)
2	238614 Whirlpool Bumper Hinge
3	WPW10058460 Whirlpool Appliance Levelling Leg
4	Frame, Front
5	Pin, Hinge Ear (2)
6	Seal, Door
7	Pushnut (2)
8	Hinge (L.H.)
8	Hinge (R.H.)
9	Oven (30“ Pyro)
9	Screw (3)
10	Socket, Oven Light (Alt.)
10	Socket, Oven Light
10	Socket, Oven Light (Alt.)
11	RANGE ONLY 40W 120V APPL BULB
12	Cover, Light
13	Retainer, Light
14	Plug Button
15	Bracket, Oven (Mounting)
16	Vent, Oven
16	Screw, 10A x 1/2 (2) (Black)
19	Channel, Arm (2)
20	WP307986 Whirlpool Hinge Pin
21	Retainer Ring (2)
22	WP308126 Whirlpool Door Spring
23	WP308125 Whirlpool Microwave Range/Cooktop Anchor
24	Wire Cover-Controls (Right)
24	Wire Cover
24	SCREW
25	Switch, Door
26	Snubber, Door (2)
27	8273888A Whirlpool Range Oven Anchor Anti-Tip Bracket Kit
27	Screw
28	Golden Harvest (Uncut)
28	Grease
28	Toast
28	8212471 Whirlpool Oven Paint
28	Paint, Spray (13 Oz.) (Platinum)
28	Enamal, Toast (1 Qt. Uncut)
28	Enamel, New Avocado (1 Qt. Uncut)
28	72113 Whirlpool Touch-Up Paint
28	72110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
28	Leveler (Thinner) (2oz.)
28	350930 Whirlpool White Spray Paint
28	Anchor, Plastic
28	350956 Whirlpool Spray Assembly
28	72017 Whirlpool Appliance Touch-Up Paint White
28	799344 Whirlpool Refrigerator Paint
28	WP72107 Whirlpool Touchup
28	Almond (Uncut)
28	Golden Harvest
28	Enamel, Coffee (1 Qt. Uncut)
28	1
28	350942 Whirlpool Spray Paint
28	WPL 799832
28	Wire, 25` Roll (Black 14 Ga.)
28	Wire, 25` Roll (Red 14 Ga.)
28	Wire, 25“ Roll (White 14 GA.)
28	285006 Whirlpool Spray
28	72109 Whirlpool Dacor Avocado Touch-Up Paint
28	Paint, Touch-Up 1/2 Oz. (Coffee)
28	paint, spray 13 oz. (coffee)
28	WPL 72112
28	Platinum (Uncut)
28	Wire (14 Ga. 200 c Brown)
28	18 Ga. 80~c Rating (Red)
28	Wire (12 Ga. 150 c Black)
28	Wire (14 Ga. 150 c Yellow)
28	Wire (14 Ga. 150 c Orange)
28	Wire (14 Ga. 150 c Green)
28	Wire (14 Ga. 150 c Brown)
28	Wire (14 Ga. 150 c Blue)
28	242831 Whirlpool Oven Wire
28	Paint, Spray 13 Oz. (Avocado)
