RF4700XEN1 05 – CONTROL PANEL, LIT/OPTIONALadmin2025-04-26T12:34:37+00:00RF4700XEN1 05 – CONTROL PANEL, LIT/OPTIONAL
Products
| Position | Product |
|---|
| Literature Parts (Instructions, Installation) |
| WPL LIT4372897 |
| WPL LIT4372851 |
| Literature Parts (Use & Care Guide) |
| 1 | Panel, Backguard (White) |
| 1 | Panel, Backguard (Almond) |
| 2 | Bracket, Endcap (R.H.) |
| 2 | Bracket, Endcap (L.H.) |
| 3 | End Cap (R.H. Almond) |
| 3 | End Cap (L.H. Almond) |
| 3 | End Cap (L.H. White) |
| 3 | End Cap (R.H. White) |
| 4 | Screw, Endcap 8-18 x 1/2 (4) |
| 5 | Clock, Timer |
| 5 | Overlay, Clock |
| 6 | Screw |
| 7 | WP486579 Whirlpool Air Conditioner Screw |
| 7 | Switch, Infin. (4) |
| 8 | Knob, Control (4) |
| 11 | Screw, 8-32 x 3/16 (2) |
| 11 | Thermostat, Oven (Auxiliary Oven) |
| 12 | Screw |
| 12 | Bracker, Clock Mtg |
| 14 | Screw Auxiliary Oven |
| 14 | Knob, Control Auxiliary Oven |
| 15 | Light, Indicator (Indicator, Oven (2)) |
| 16 | Lens, Indicator |
| 17 | Switch, Rocker |
| 18 | Cover, Backguard |
| 20 | WPL 4372869 |
| 20 | Golden Harvest |
| 20 | Trim, Backguard |
| 20 | Wire (14 Ga. 150 c Green) |
| 20 | Grease |
| 20 | Wire, 25` Roll (Red 14 Ga.) |
| 20 | Wire, 25` Roll (Black 14 Ga.) |
| 20 | WPW10208653 Whirlpool Insulation |
| 20 | WPL 799832 |
| 20 | 350942 Whirlpool Spray Paint |
| 20 | Golden Harvest (Uncut) |
| 20 | 72110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz |
| 20 | Almond (Uncut) |
| 20 | WP72107 Whirlpool Touchup |
| 20 | 799344 Whirlpool Refrigerator Paint |
| 20 | 72017 Whirlpool Appliance Touch-Up Paint White |
| 20 | 350956 Whirlpool Spray Assembly |
| 20 | Wire, 25`` Roll (White 14 GA.) |
| 20 | 285006 Whirlpool Spray |
| 20 | 72109 Whirlpool Dacor Avocado Touch-Up Paint |
| 20 | 1 |
| 20 | Wire (14 Ga. 200 c Brown) |
| 20 | 18 Ga. 80~c Rating (Red) |
| 20 | Wire (12 Ga. 150 c Black) |
| 20 | Wire (14 Ga. 150 c Yellow) |
| 20 | Wire (14 Ga. 150 c Orange) |
| 20 | Wire (14 Ga. 150 c Brown) |
| 20 | Wire (14 Ga. 150 c Blue) |
| 20 | 242831 Whirlpool Oven Wire |
| 20 | Paint, Spray 13 Oz. (Avocado) |
| 20 | paint, spray 13 oz. (coffee) |
| 20 | Paint, Touch-Up 1/2 Oz. (Coffee) |
| 20 | 350930 Whirlpool White Spray Paint |
