RG34NL1 02 – CONTROL PANEL

Products

Position	Product
*35671	WCI 08003252
1	COVER, WIRE.
2	5303935086 Frigidaire Oven Top Burner Switch Kit
3	WCI 5303211173
4A	IND LITE OVEN
4	LIGHT - PILOT SURFACE UNIT
5	LENS (3)
6	WCI 08015934
7	WCI 5303211172
8	KNOBS-GRAY & BURGUNDY (6)
9A	WCI 08012554
9	WCI 08012555
10	SUPPORT RH
10A	SUPPORT - LH
11	BRACKET, HINGE (2)
12	WCI 5303211170
13	WCI 5303211385
14	KNOB - CLOCK (3) - GREY
15	BRACKET-MTG CLOCK
