RG35AL4 02 – CONTROL PANEL

Written by

Products

Position	Product
1	COVER, WIRE.
2	5303935086 Frigidaire Oven Top Burner Switch Kit
3	THERMOSTAT – OVEN
4A	IND LITE SURF UNIT
4	INDICATOR LIGHT, OVEN
5	LENS (2)
6	WCI 08015934
7	WCI 08016518
8	WCI 5308015741
9A	WCI 08012554
9	WCI 08012555
10	SUPPORT RH
10A	SUPPORT LH
11	BRACKET, HINGE (2)
12	WCI 08016483
13	WCI 08012708
14	WCI 08004148
15	BRACKET-MTG CLOCK
