RGE3210W0 03 – SECTION

Products

Position	Product
	Almond (Uncut)
	Enamel, New Avocado (1 Qt. Uncut)
	511873 Whirlpool Refrigerator Paint
	Golden Harvest (Uncut)
	Enamel, Coffee (1 Qt. Uncut)
	799344 Whirlpool Refrigerator Paint
1	Cooktop (Almond)
1	Cooktop (Coffee)
1	Cooktop (New Avocado)
1	Cooktop (Golden Harvest)
1	Cooktop (White)
2	Light, Signal (125V) (Surface Unit)
3	Light, Signal (Oven) (250V)
4	W10900107 Whirlpool Oven Surface Element Switch
4	WP486579 Whirlpool Air Conditioner Screw
5	Thermostat, Oven
6	Sleeving, Insulating
7	WPL 486525
7	Switch, Oven Selector
8	Indicator, Oven Selector (1)
9	Indicator, Surface Unit (4)
10	Knob & Skirt Assembly (Surface Unit) (4)
11	Knob & Skirt Assembly (Thermostat) (1)
12	Knob & Skirt Assembly (Oven Selector) (1)
13	Hinge Pin, Cooktop (R.H.)
13	Hinge Pin, Cooktop (L.H.)
14	Hinge, Oven Door (Auxiliary) (Screw, 8-32 x 3/8 (2) (Top))
14	Duct, Wire
15	WPL 868383
16	Retainer, Hinge Pin (2)
17	WPW10196406 Whirlpool 6" Chrome Drip Bowl
18	DRIP BOWL 8" W/HOLE CHROME
19	WP660532 Whirlpool Oven Surface Element
20	WP660533 Whirlpool Oven 8" Surface Element
21	WPL 868522
22	WPL 868384
22	WPL 868387
22	WPL 868385
22	WPL 868388
22	WPL 868386
23	WPL 868396
23	Screw, 10-24 x 1/2 (3)
24	Leveler (Thinner) (2oz.)
24	WPW10208653 Whirlpool Insulation
24	FOIL, ALUMINUM OVEN (18“ X 25 )
24	Wire, 25` Roll (Black 14 Ga.)
24	Wire, 25` Roll (Red 14 Ga.)
24	Wire, 25“ Roll (White 14 GA.)
24	285006 Whirlpool Spray
24	WP486754 Whirlpool Compactor Screw
24	Golden Harvest
24	WPL 799832
24	350942 Whirlpool Spray Paint
24	BURNER RECEPTACLE KIT
24	72110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
24	WP72107 Whirlpool Touchup
24	72017 Whirlpool Appliance Touch-Up Paint White
24	WPL 868931
24	WPL 884027
24	350956 Whirlpool Spray Assembly
24	72109 Whirlpool Dacor Avocado Touch-Up Paint
24	WPL 865621
24	Grease
24	WPL 799351
24	WPL 308500
24	1
24	Wire (14 Ga. 200 c Brown)
24	18 Ga. 80~c Rating (Red)
24	Wire (12 Ga. 150 c Black)
24	Wire (14 Ga. 150 c Blue)
24	Wire (14 Ga. 150 c Yellow)
24	Wire (14 Ga. 150 c Orange)
24	Wire (14 Ga. 150 c Green)
24	Wire (14 Ga. 150 c Brown)
24	242831 Whirlpool Oven Wire
24	Touch-Up Oven (1 Oz.)
24	Paint, Spray 13 Oz. (Avocado)
24	paint, spray 13 oz. (coffee)
24	Paint, Touch-Up 1/2 Oz. (Coffee)
24	350930 Whirlpool White Spray Paint
