RGL3636AL0 02 – TOP AND CABINET, LIT/OPTIONAL

Products

PositionProduct
350930 Whirlpool White Spray Paint
Leveler (Thinner)
WP72107 Whirlpool Touchup
799344 Whirlpool Refrigerator Paint
List, Service Parts
72017 Whirlpool Appliance Touch-Up Paint White
Instructions, Installation
350956 Whirlpool Spray Assembly
350938 Whirlpool Spray Gun
Use & Care Guide
Almond (Uncut)
1Panel, Rear Console
3WPW10139210 Whirlpool Screw
4Cap, End (L.H.)
6WP488729 Whirlpool Refrigerator Door Screw
7Cap, End (R.H.)
8WP489069 Whirlpool Compactor Screw
9WP693995 Whirlpool Screw
10339392V Whirlpool Dryer Lint Filter Screen
11Cover, Lint Screen (Almond)
11Cover, Lint Screen (White)
12WPW10044480 Whirlpool Hinge Assembly
12WPW10044470 Whirlpool Hinge Assembly
13W11693756 Whirlpool Screw Assembly
14WP388326 Whirlpool Screw
15Clip, Retainer
16Top (Almond)
16Top (White)
178283286 Whirlpool Wire Harness
18WP94614 Whirlpool Terminal
19Knob, Temperature
21WP3976568 Whirlpool Timer
30WP357213 Whirlpool Hinge Stopper
31Harness, Wiring
39(Alt.)
39Switch, Push-To-Start
48Timer Knob Assembly
53Bracket, Control
54Panel, Control
67WP689559 Whirlpool Nut
72Wire, Ground
75353424 Whirlpool Connector
75Receptacle, 3-Way Terminal (Use W/94614)
79Switch, Temperature
81Knob, Push-To-Start
84WP596797 Whirlpool Terminal
