RGL5646AL0 02 – TOP AND CABINET, LIT/OPTIONAL

Products

Position	Product
	Instructions, Installation
	List, Service Parts
	Use & Care Guide
	Almond (Uncut)
	Leveler (Thinner)
	WP72107 Whirlpool Touchup
	799344 Whirlpool Refrigerator Paint
	72017 Whirlpool Appliance Touch-Up Paint White
	350956 Whirlpool Spray Assembly
	350930 Whirlpool White Spray Paint
	350938 Whirlpool Spray Gun
1	Panel, Rear Console
3	WPW10139210 Whirlpool Screw
4	Cap, End (L.H.)
5	Clip, Retainer
6	WP488729 Whirlpool Refrigerator Door Screw
7	Cap, End (R.H.)
8	WP489069 Whirlpool Compactor Screw
9	WP693995 Whirlpool Screw
10	339392V Whirlpool Dryer Lint Filter Screen
11	Cover, Lint Screen (White)
11	Cover, Lint Screen (Almond)
12	WPW10044480 Whirlpool Hinge Assembly
12	WPW10044470 Whirlpool Hinge Assembly
13	W11693756 Whirlpool Screw Assembly
14	WP388326 Whirlpool Screw
15	Wire Jumper Assembly
16	Top (Almond)
16	Top (White)
17	Wire, Jumper (Violet)
17	Wire, Jumper (Blue)
18	WP94614 Whirlpool Terminal
19	Knob, Temperature
21	WP3396047 Whirlpool Timer
30	WP357213 Whirlpool Hinge Stopper
31	Harness, Wiring
39	Relay, Push-To-Start
48	Timer Knob Assembly
53	Bracket, Control
54	Panel, Control
67	WP689559 Whirlpool Nut
72	Wire, Ground
75	353424 Whirlpool Connector
75	Receptacle, 3-Way Terminal (Use W/94614)
76	WP694419 Whirlpool Buzzer Adjuster
79	Switch, Rotary (Temperature Selector)
81	Knob, Push-To-Start
84	WP596797 Whirlpool Terminal
