| Order Blank, Filter |
| Repair Parts List |
| Installation & Operating Instructions |
| 1 | WP8190232 Whirlpool Refrigerator Light Lens and Filter |
| 2 | W10673703 Whirlpool Rocker Switch |
| 3 | Bushing, Strain Relief |
| 4 | Nameplate |
| 5 | Switch, Fan |
| 6 | Receptacle, Light |
| 7 | Blade, Fan |
| 8 | Motor, 2-Speed |
| 9 | Bracket, Motor |
| 10 | WP489069 Whirlpool Compactor Screw |
| 11 | Cover, Wiring (Almond) |
| 11 | Cover, wiring (White) |
| 11 | Cover, Wiring (Toast) |
| 11 | Cover, Wiring (Platinum, Stainless) |
| 13 | WP488130 Whirlpool Air Conditioner Nut |
| 14 | Retainer, 3/16 |
| 15 | SCREW |
