RHE396PP 02 – OVEN

Products

Position	Product
1	Shield, Wire
2	Cover, Vent Duct
3	Gasket, Duct
4	Duct, Sub Top
6	WPL 595119
6	Housing, Latch
7	Panel, Sub Top
9	Cooktop (Chrome)
11	WPL 486525
11	Terminal, Female (10)
12	Clip, Receptacle (4)
12	Model KIH160UK (Cord Only)
13	Receptacle, Female (2)
14	Tape Foam (Cooktop)
15	Seal, Cooktop (1)
16	Screw 10-24 x 1/2
16	Frame, Cooktop
17	WPL 273225
17	Motor (Alternate)
18	Switch, Lower Limit (2) (Alternate)
19	Switch, Upper Limit (Alternate)
19	Switch, Upper Limit (Screw, 4-40 x 1-1/4 (2))
20	Insulator, Limit Switch (3)
21	Cam, Door Latch (Pushnut, 3/16“)
22	Cam, Door Latch (Pin, Spring)
22	cam, door latch (alternate)
23	Tie Bar
24	WP8283288 Whirlpool Door Switch
25	Retainer, Spring
25	Rod, Switch
26	Plug Button
27	Socket, Light
27	WPL 834649
28	Gasket, Light
29	RANGE ONLY 40W 120V APPL BULB
30	Cover, Light
31	retainer, oven light
32	Unit Bake (Screw, 10-24 x 1/2 (2))
32	Bracket, Thermo Bulb
33	Plug, Button
34	Bracket, Door Switch
34	Screw, 10-24 x 1/2 (3)
35	Latch, Door
35	Washer (2)
36	Pushnut, 1/4
36	Axle, Latch
37	Button, Plug
