RHE396PP 03 – BACKGUARD

Products

Position	Product
1	Cover Wiring, Low
2	Back
2	Nut, Speed (4)
3	Gusset, Rear (L.H.)
3	Gusset, Rear (R.H.)
5	Cover
6	Hex Nut, 10-32 (6)
6	WP8203546 Whirlpool Terminal Block
6	Washer (Ground) (3)
8	Ballast
8	Model KIH160UK (Cord Only)
9	Panel, Bottom
10	Channel, Oven Support
10	WPL 834649
11	Bracket, Cooktop
12	Oven, Self-Clean
13	Tube, Oven Vent
13	WP965173 Whirlpool Dishwasher Screw
13	Screw, 10-24 x 3/8 (2)
14	End Panel, Almond (R.H.)
14	Screw, 10-24 x 1/2 (3)
14	End Panel, Almond (L.H.)
15	Retainer, Insulation (R.H.)
15	Retainer, Insulation (L.H.)
17	Leg Leveler (4)
18	Unit, Broil
19	Hanger, Broil Unit
20	4396923 Whirlpool Broil Pan Set Gray Porcelain
21	Pan, Broiler
22	Rack, Oven Offset
22	WPL 865983
23	WPL 799351
23	Kit, Roller (Rail Assembly & Drawer)
23	Wire, 18 Ga. (Red) (25 Ft.)
23	Wire, 14 Ga. (White) (25 Ft.)
23	WPL 980493
23	WPL 868790
23	WPL 865621
23	WPL 253883
23	350956 Whirlpool Spray Assembly
23	Unit Bake (Screw, 10-24 x 1/2 (2))
23	WP865940 Whirlpool Bake Element
23	Paint, Touch-Up 1 Oz. (Oven Liner) (Light Gray)
23	WPL 308500
23	WPW10208653 Whirlpool Insulation
23	Almond (Uncut)
23	WPL 253886
23	WPL 253893
23	WPL 253894
23	WPL 834470
23	WPL 834469
23	WPL 253906
23	WPL 253904
23	WPL 253901
23	WPL 253900
23	WPL 253897
23	WPL 253895
23	WP72107 Whirlpool Touchup
