RHE396PP 04 – DOOR AND DRAWERadmin2025-04-26T12:05:39+00:00RHE396PP 04 – DOOR AND DRAWER
Products
| Position | Product |
|---|
| 1 | Cover, Wiring |
| 2 | Shade, Lamp |
| 2 | Screw, 6-32 x 5/16 |
| 3 | Channel, Light Mounting |
| 4 | Switch, Fluorescent Light |
| 5 | WPL 866053 |
| 6 | WPL 866138 |
| 6 | WPL 98754 |
| 7 | Switch, Oven Selector |
| 8 | WPL 868808 |
| 10 | End Cap (L.H.) |
| 10 | End Cap (R.H.) |
| 10 | Nut, Timer (4) |
| 10 | Unit Bake (Screw, 10-24 x 1/2 (2)) |
| 11 | Support, Backguard (R.H.) |
| 11 | Support, Backguard (L.H.) |
| 12 | Lamp, Fluorescent |
| 13 | Switch, Infinite (4) |
| 13 | WPL 486525 |
| 14 | Motor, Timer |
| 15 | Light, Pilot (3) (Clean, Lock & Surface Unit) |
| 15 | Light, Pilot (Oven) |
| 16 | Base, Backguard |
| 16 | WP308685 Whirlpool Microwave Screw |
| 16 | Screw, 10-24 x 1/2 (3) |
| 17 | WPL 834956 |
| 18 | WPL 487428 |
| 18 | Model KIH160UK (Cord Only) |
| 18 | Lampholder (R.H.) |
| 18 | Lampholder (L.H.) |
| 19 | Bracket, Control (Not Serviceable) |
| 21 | Hex Nut, 10-32 (6) |
| 21 | Timer, Complete (Includes Illus. 14 & 24) |
| 22 | Panel, Glass |
| 23 | Trim, Glass (2) |
| 24 | Knob, Timer (3) |
| 25 | Knob, Surface Units (4) |
| 26 | Gasket, Duct |
| 27 | Duct, Oven Vent |
| 28 | Dial, Surface Unit (4) |
| 29 | Knob, Control (2) (Oven Selector & Thermostat) |
| 30 | Screw 10-24 x 1/2 |
| 30 | Gusset, Backguard (2) |
