RHM975PW2 02 – CONTROL PANEL, DOOR AND LATCH

Products

Position	Product
1	door, complete
2	Handle, Door
3	Button, Door Handle
4	Rear Top Burner-Lt. or Rt. (Inc`s 64 & 65)
5	Bracket, Door Handle
6	WP489128 Whirlpool Refrigerator Screw
7	frame, control panel
8	panel, glass touch
9	p.c. board, touch panel
10	display assembly, l.e.d. (includes illus. 12)
11	Switch, Light
12	clock, l.e.d.
13	Cabinet (Not A Serviceable Part)
14	harness, power supply
15	harness, touch panel
16	Screw
17	WPW10068250 Whirlpool Dishwasher Screw
19	Seal, Top & Bottom (2) (Alternate)
19	Seal, Top & Bottom (2) (Alternate)
20	Retainer, Top & Bottom Seals (2)
21	Seal, Sides (Alternate)
21	Seal, Sides (Alternate)
22	Retain, Side Seal (2)
23	Latch, Door
24	clip, clock to socket (2)
26	plunger, latch
29	Screw, 8-32 x 5/16 (2)
32	Pin, Roller (2)
33	gasket, control panel frame
34	film, light diffusing (3)
35	Screw, 8-18BT x .88 (2)
36	WPL 309080
40	switch kit, door (kit contains primary, monitor & secondary switches. All 3 switchs must be replace
41	Insulator, Switch (Top)
43	Screw
44	Bracket, Primary Switch
45	WP488627 Whirlpool Refrigerator Screw
47	WPL 310629
49	End Cap, Door
50	Ring, Retaining (2)
52	Cam
53	WPL 310120
54	WPL 310386
55	WPL 310343
56	Top Vent Box
77	WPL 310951
78	WPL ARI123393A
79	WPL ARI123394A
80	Foam Strip 14“ x 3/8“ x 1/2“xxx
81	WPL 310154
82	Screw, 4-40 x 10 (2)
84	WPL 310124
85	Rear Top Burner-Rt. or Lt. (Inc`s. 32 & 33)
86	WPL 328655
87	Rivet, Pop (3)
