RHM975PW2 03 – CABINET, HINGE AND STIRRER , LITERATURE

Products

PositionProduct
1Foot, Mounting
2hinge door (bottom)
2hinge door (top)
3plate, hing (2) (top & bottom)
5Hinge, Shim Locking (2)
7Base, Ceramic (Install W/Silastic No. 482338)
7Shelf, Microwave (Alt.)
8panel, top (screw, 10a x 3/8 (3))
9Motor, Stirrer (Alternate)
9motor, stirrer (alternate)
11Screw
12Stirrer Blade
13Nut, Hex (1/4-20)
14Cover, Stirrer
16Main Chassis (Screw, 10-32 x 1/2)
17WPL 312147
18Shield, Exhaust Probe
19Base & Cavity Assembly (Not Serviceable)
20Screw, 10A x 1/2 (2) (Black)
21Cover, Lamp
22Socket, Snap-In
23RANGE ONLY 40W 120V APPL BULB
24screw, oval head (4)
25Cord, Power (Alternate)
25cord, power (alternate)
26Baffle, Air Exhaust
28Fastener (2)
29Fuse, Thermal
30Hex Nut, 10-32 (2)
31Jack, Probe
32Washer, Internal Lock
33Nut
34temperature probe (alternate)
34temperature probe (alternate)
35Washer
36Wrapper, Cabinet
41Cover, Rivet
43rack, oven
44Support, Shelf (4)
46WPL 832769
46WPL 832765
46WPL 980651
46WPL 832810
46Wire (14 Ga. 150 c Brown)
46WPL 832790
46WPL 590014
46WPL 398295
4618 Ga. 80~c Rating (Red)
46Wire (12 Ga. 150 c Black)
46Wire (14 Ga. 150 c Yellow)
46Wire (14 Ga. 150 c Orange)
46Wire (14 Ga. 150 c Green)
46Wire (14 Ga. 150 c Blue)
46WP261869 Whirlpool Microwave Paint
46242831 Whirlpool Oven Wire
46WP482338 Whirlpool Refrigerator Adhesive
46Wire, 25“ Roll (White 14 GA.)
46Wire, 25` Roll (Red 14 Ga.)
46Wire (14 Ga. 200 c Brown)
461
46WPL 328022
46WPL 311490
46WPL 311308
46WPL 308294
46WPL 261940
46WPL 310848
46WPL 307843
46Spacer-Oven Door Glass (Lt. or Rt.)
46WPL 832763
46Pilot Cup (3 Req)
46261900 Whirlpool Microwave Spray
46Wire, 25` Roll (Black 14 Ga.)
