RHM975PW2 04 – MAGNETRON AND AIRFLOW

Products

Position	Product
1	Cabinet (Not A Serviceable Part)
2	resistor, power (3 ohm)
3	Deflector, Air
4	Flange Nut (4)
5	Main Chassis (Screw, 10-32 x 1/2)
6	Transformer
7	resistor (2 watt 10m ohm)
8	Bracket, Capacitor
9	Block, Fuse
10	bracket, support
11	block, terminal
12	WPW10017410 Whirlpool Fuse
13	WPL 310629
14	Reed Relay (Alternate)
14	Relay, Reed
16	Guide, Wave (Riveted At Assembly, Not Serviceable)
17	Cabinet Side (Left)
17	Cabinet Side (Right)
18	Rectifier, High Voltage
19	WP854334 Whirlpool Air Conditioner Sealing Strip
20	Duct, Cooling Air
21	WP965173 Whirlpool Dishwasher Screw
22	gasket, magnetron
24	Magnetron (Alternate)
24	magnetron (alternate)
25	Screw, Tapping
26	Blade, Fan
27	mount, fan motor
28	Nut
29	Motor, Fan (Alternate)
29	Motor Fan (Alternate)
30	Clip (4)
31	Wire, High Voltage (Capacitor)
32	WPW10339879 Whirlpool Wire Tie
33	Deflector, Exhaust
34	Clip (2)
35	fastener, speed nut
37	Thermostat
38	SCREW
39	8528351 Whirlpool Clip
40	Transformer & Harness Assembly
41	relay power (12 v.d.c.) (alternate)
41	relay power (12 v.d.c.) (alternate)
42	Front Panel-Oven Door (White)
42	relay power (120 vac) (alternate)
43	Powe
44	WPL 61096
45	WP486754 Whirlpool Compactor Screw
47	WPL 310956
48	Shield, Fuse
49	Spacer (2 Req)
50	Screw
51	Lockwasher
52	WPL 310432
53	Fastener (2)
54	WPL 311466
55	WPL 311467
56	Screw, 10-32 x 1/2 Hex Washer W/Ground Ring (10)
