RJM1870P1 04 – LINERadmin2025-04-26T12:06:22+00:00RJM1870P1 04 – LINER
Products
| Position | Product |
|---|
| 1 | Frame, Oven Door |
| 3 | Nut |
| 3 | Screw, 6-32 x 3/8 (4) |
| 3 | Grip, Handle |
| 4 | Glass, Outer |
| 5 | Panel, Heat Reflector |
| 6 | Liner, Oven Door |
| 7 | Baffle |
| 8 | Seal, Oven Door |
| 9 | Window |
| 10 | Panel, Air Wash |
| 11 | Plug Button 3/16`` (2) |
| 12 | ``J`` Moulding |
| 19 | Screw |
| 19 | Channel Assembly (2) |
| 19 | Washer (2) |
| 20 | Roller, Stop (2) |
| 21 | Nut, Speed |
| 21 | Rivet (2) |
| 22 | Pin, Hinge (2) |
| 23 | Arm, Hinge (2) |
| 24 | Spring, Door (2) |
| 25 | Washer (4) |
| 25 | Screw 10-24 x 1/2 |
| 25 | Strike |
| 25 | W10080180 Whirlpool Nut |
| 26 | Glass, Inner |
| 27 | Retainer, Glass |
| 27 | Screw, 10-24 x 1/2 (3) |
