RM988PXVF2 05 – UNIT

RM988PXVF2 05 – UNIT

Written by

in

RM988PXVF2 05 – UNIT

Products

PositionProduct
Screw (2)
1Bracket, Mounting (2)
2Screw, 10A x 1/2 (2) (Black)
2Rail R.H. (Includes Illus. 3)
2Rail L.H. (Includes Illus. 3)
3Glide, Front (2)
4ELMNT-BAKE
5WP660579 Whirlpool Range Wall Oven Broil Element, 3000W, 240V
6WP8203546 Whirlpool Terminal Block
6Screw, (2) 10-16 x 1
7WPL 308498
7Clip, Ground Wire
8Bracket, Service
10Cover, Rear
11Cover, Service
11WP112432 Whirlpool Nut Assembly
134396923 Whirlpool Broil Pan Set Gray Porcelain
14WPL 308173
15WPL 308172
16WPL 312318
16WPL 311982
17Cover
18SCREW
18Plate, Mounting Terminal Block
19Strain Relief (3)
19WP488729 Whirlpool Refrigerator Door Screw
20Barrier, Shield
