RS192MCF0 07 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

Position	Product
*30512	5303017691 Frigidaire Refrigerator Spacer-Tube
*30512	WCI 08009619
*30512	240396801 Frigidaire Refrigerator Tube Clamp
*30512	5303001199 Frigidaire Refrigerator Wiring Harness Clamp
*30511	WCI G189379
*30512	SLEEVE-CONNECTOR
1	WCI 08017228
2	BRACKET-CONDENSER MOUNTING (4)
3A	WCI 08009617
4	5303006412 Frigidaire Refrigerator Cover Mounting Strap
5	5303305677 Frigidaire Replacement Filter Dryer Filters
5B	218843801 Frigidaire Refrigerator Screw
6	WCI 5303916605
7	5303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
8	WCI 08017565
9	WCI 08000828
10	WCI 3001235
11	WCI 3007568
12	WCI 08002777
13	5308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
14A	5308000039 Frigidaire Refrigerator Screw
14B	WCI 08000099
14	DEFROST PLATE & TUBE ASSY
15	WCI 3001197
16	WCI 3015098
17	WCI 08009616
18	CORD, SERVICE
20	5304455651 Frigidaire Refrigerator Screw
21	WCI 08950223
22	CLIP (4)
23	WCI 08003633
24	218513300 Frigidaire Refrigerator Compressor Mount Grommet
25	WCI 3007173
26	5303271616 Frigidaire Refrigerator P1-Overload
28	CAPACITOR-RUN
