RS19F3YX1B 04 – CABINET PARTS

Products

Position	Product
*39706	INSULATION-BULK (NON-ILLUSTRATED)
3	Nut,push-on
10	WCI 5303006543
10A	COVER-COIL LOWER
10B	NUT, “U“ TYPE, NO. 8-15(A), FAN MOTOR MOUNT (NOT ILLUSTRATED)
11	5303208309 Frigidaire Refrigerator Plug Hole
11	WCI 5303916982
12	WCI 5303275307
14	WCI 5315230801
18	WCI 5303275497
18A	WCI 5303001250
18	SUPPORT-COIL COVER
19	TUBE-RUBBER
20	WCI 5303001286
21A	WCI 5308011745
21	WCI 5303001287
22	BEARING-HINGE
22	WCI 5303001022
23	WCI 5303209723
23	WCI 5303001020
23A	CLAMP-TUBE
28	SCREW-ROLLER ADJ (2) (NON-ILLUSTRATED)
29	WASHER, .28 X .62 X .19, NYLON
30	HINGE-BOTTOM
31	SHIM-BTM HINGE (3)
33	WCI 5308000086
33A	WCI 08000099
34	WCI 5308000186
34	WCI 5308000790
35	WCI 5303200272
38	WCI 5303001062
38A	WCI 5308012934
38C	TAPPING PLATE, UPPER HINGE (2) (NOT ILLUSTRATED)
38B	241710601 Frigidaire Refrigerator Screw
39	SHIM – UPPER HINGE
40	COVER – HINGE-WHEAT
41	5304509705 Frigidaire Refrigerator Grommet
42	SCREW-HINGE MTG (2) (NON-ILLUSTRATED)
58	5304455651 Frigidaire Refrigerator Screw
