RS226GCF2 07 – SYSTEM AND AUTOMATIC DEFROST PARTS

RS226GCF2 07 – SYSTEM AND AUTOMATIC DEFROST PARTS

Written by

in

RS226GCF2 07 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

PositionProduct
*67747WCI R900979
*67747WCI G189379
1WCI G189612
2WCI G169493
3WCI G157191
4EXCHANGER-HEAT
55303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
6WCI G167363
75308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
8WCI G188597
9BRACKET, COND. MTG (4)
115303305677 Frigidaire Replacement Filter Dryer Filters
12CORD, SERVICE
145303001199 Frigidaire Refrigerator Wiring Harness Clamp
155308000039 Frigidaire Refrigerator Screw
16WCI G182225-04
17WCI G188727
18OVERLOAD CLIP
205303006412 Frigidaire Refrigerator Cover Mounting Strap
21COMPRESSOR
22CLIP, COMPRESSOR MOUNTING (4)
23WASHER, COMPRESSOR MOUNTING (4)
24218513300 Frigidaire Refrigerator Compressor Mount Grommet
25BBRACKET-DEFROST PAN MTG (NON-ILLUSTRATED)
25AWCI G171111
25WCI G188596
25C218843801 Frigidaire Refrigerator Screw
26WCI G183584
27WCI G169641
