RS226GCH3 05 – SHELVES AND SUPPORTS

RS226GCH3 05 – SHELVES AND SUPPORTS

Written by

in

RS226GCH3 05 – SHELVES AND SUPPORTS

Products

PositionProduct
1CHANNEL-RS & LS
25304455852 Frigidaire Refrigerator Screw
3WCI G180195-07
4WCI G187267-13
5WCI G179709-01
6AGASKET-COVER UPR (2) (NON-ILLUSTRATED)
6COVER-PAN UPPER
7WCI G177343-06
8WCI G179710-01
9COVER-PAN-LOWER
10CONTAINER ICE
11215667501 Frigidaire Refrigerator Ice Tray Primary
12HANGER-BASKET RS
13HANGER-BASKET LS
14WCI G184748
15WCI G165746-11
16SHELF-FREEZER (2)
17WCI 3015092
18SHELF-FREEZER CTR (3)
195304509705 Frigidaire Refrigerator Grommet
20CONTAINER-EGG
