RS227MCW2 08 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

Position	Product
*55268	218843801 Frigidaire Refrigerator Screw
*55268	WCI 5308009619
*55268	WCI 5300189379
1	WCI 5303007521
2	BRACKET, MOUNTIN, CONDENSER, (4)
2A	WASHER, EXT TOOTH LOCK, NO. 10 (NON-ILLUSTRATED)
3	WCI 5308000828
4	5303305677 Frigidaire Replacement Filter Dryer Filters
5	WCI 5303015098
6	WCI 5308009616
7	CORD-ELECTRIC POWER
8	WCI 5303001197
9	WCI 5308002777
10	WCI 5308002780
11	WCI 5308002782
12	CLIP-OVERLOAD
13	WCI 5308017565
14	WCI 5303007568
15	WCI 5303916605
15A	TUBE-INLET (NOT ILLUSTRATED)
16	5308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
17	WCI 5303001235
21	5303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
23	218513300 Frigidaire Refrigerator Compressor Mount Grommet
24	WASHER-COMPR MTG
25	CLIP - COMPRESSOR MTG
29	COMPRESSOR-W/ELECTRICALS
30	216594300 Frigidaire Refrigerator Starter
31	WCI 5303210976
32	5303006412 Frigidaire Refrigerator Cover Mounting Strap
34	WCI 5308017112
41	5308000039 Frigidaire Refrigerator Screw
43	5303001199 Frigidaire Refrigerator Wiring Harness Clamp
44	5308000133 Frigidaire Refrigerator Clamp
45	5304455651 Frigidaire Refrigerator Screw
