RS229MCF2 10 – SYSTEM AND AUTOMATIC DEFROST PARTS

RS229MCF2 10 – SYSTEM AND AUTOMATIC DEFROST PARTS

Written by

in

RS229MCF2 10 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

PositionProduct
*21972WCI 5300189379
1WCI 5303007521
2BRACKET, MOUNTIN, CONDENSER, (4)
3AWASHER, EXT TOOTH LOCK, NO. 10 (NON-ILLUSTRATED)
45303006412 Frigidaire Refrigerator Cover Mounting Strap
55303305677 Frigidaire Replacement Filter Dryer Filters
6ATUBE-INLET (NOT ILLUSTRATED)
6WCI 5303916605
75303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
8WCI 5308017565
8A5308000133 Frigidaire Refrigerator Clamp
9WCI 5308000828
10WCI 5303001235
11WCI 5303007568
12WCI 5308002777
135308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
14B5308000039 Frigidaire Refrigerator Screw
14AWCI 5308002782
14CWCI 5308002780
14WCI 5308017112
14D218843801 Frigidaire Refrigerator Screw
15WCI 5303001197
16WCI 5303015135
17WCI 5308009616
18CORD-ELECTRIC POWER
195303001199 Frigidaire Refrigerator Wiring Harness Clamp
205304455651 Frigidaire Refrigerator Screw
21COMPRESSOR WITH ELECTRICALS
22CLIP – COMPRESSOR MTG
23WASHER-COMPR MTG
24218513300 Frigidaire Refrigerator Compressor Mount Grommet
25RELAY-TL
26WCI 5308017526
27CAPACITOR
