RS22AMXVL00 05 – REFRIGERATOR DOOR

RS22AMXVL00 05 – REFRIGERATOR DOOR

Written by

in

RS22AMXVL00 05 – REFRIGERATOR DOOR

Products

PositionProduct
1Refrigerator Door (Almond)
1Refrigerator Door (White)
2Tap Plate
34318165 Whirlpool Refrigerator Door Closure Cam Kit
4WP489069 Whirlpool Compactor Screw
5Bracket, Door Stop
6Shim
7Screw, 89 x 5/8
8WP1104787 Whirlpool Refrigerator Shim
9Hole Plug (2)
10End Cap
11Handle End, Side
122188404A Whirlpool Refrigerator Door Gasket
13Cap, Hinge Sleeve (2)
14Handle, Center
15Shim
16WP488729 Whirlpool Refrigerator Door Screw
17WP939101 Whirlpool Refrigerator Plate
18Screw
19Insert, Extension
20Insert, Extension
21Insert Retainer (Top)
22Retainer, Insert (Bottom)
23Screw, 10-32 x 5/8
24Shim, Handle
25End Cap
26Screw Anchor (2)
27Interior, Door Panel
28Trim, Shelf (5)
29Retainer, Door Trim (10)
30Door, Compartment
31Nameplate
32Trim, Compartment Door
