RS249JCD1 07 – REFRIGERATOR CONTROL ASSEMBLY, DAMP

Products

Position	Product
1	WCI R900978
2	5308000010 Frigidaire Refrigerator Evaporator Fan Blade
3	RING, FAN ORIFICE
4	WCI G185302
5	WCI G185303
6	G187559 Frigidaire Refrigerator Bushing
7	5300158289 Frigidaire Evaporator Fan Motor
8	WCI G164571
9	WCI G164575
10	WCI G164523
11	KNOB, DAMPER CONT.
12	WCI G185373
13	WCI G165545
14	WCI G166068
15	COVER CONT. BRACKET
16	WCI G162205-05
17	WCI G107080
18	5304455649 Frigidaire Refrigerator Screw
19	TUBE
20	WCI G164788
21	WCI G164906-01
22	WCI G165543
23	SOCKET LIGHT
24	WCI Q63749
25	215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
26	WCI G166802
27	WCI G166803
28	WCI G167582
29	5304455650 Frigidaire Refrigerator Screw
30	5308000039 Frigidaire Refrigerator Screw
