RS249MCD0 06 – REFRIGERATOR CONTROL ASSEMBLY, DAMP

RS249MCD0 06 – REFRIGERATOR CONTROL ASSEMBLY, DAMP

Written by

in

RS249MCD0 06 – REFRIGERATOR CONTROL ASSEMBLY, DAMP

Products

PositionProduct
*25794WCI 5308000809
*25794WCI 5308000808
1WCI 5303001779
2SOCKET-LIGHT/LAMP
35304455649 Frigidaire Refrigerator Screw
4215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
5WCI 5308017561
5AWCI 3001269
6WCI 5303001260
7KNOB-TEMP CONTROL
85304455852 Frigidaire Refrigerator Screw
9WCI 5308000068
10TUBE
11WCI 5303001276
12AWCI 5303001280
12WCI 5303001277
13WCI 5308000771
14A5304455650 Frigidaire Refrigerator Screw
14WCI 5303001252
15WCI 5308013429
16WCI 5316521701
17WCI 5303001227
18WCI 5308000107
20G187559 Frigidaire Refrigerator Bushing
215300158289 Frigidaire Evaporator Fan Motor
22WCI 5303001226
235308000010 Frigidaire Refrigerator Evaporator Fan Blade
24RING-FAN ORIFICE
25218843801 Frigidaire Refrigerator Screw
26WCI 5308015764
