RS33BNL2 06 – BODY PARTS

RS33BNL2 06 – BODY PARTS

Written by

in

RS33BNL2 06 – BODY PARTS

Products

PositionProduct
*49380WCI 19100210094
*49379WCI 3203574
*49379WCI 3205257
1WCI 5301314211
2TUBE-OVEN VENT
3INSULATION – OVEN WRAP
4WCI 5303274967
5ASIDE PANEL LH-ALMD
5SIDE PANEL RH-ALMD
6PANEL-BACK
7WCI 3206275
8AWCI 3017482
8WCI 3017481
9WCI 5303207391
10SCREW-LEVELING (4)
11WCI 3202082
12WCI 3051655
13WCI 5308015746
13ARAIL, DRAWER LH
14SPACER, DRAWER RAIL (2)
15GUIDE-DRAWER FRNT (2)
16BUMPER, COOKTOP (4)
17WCI 3019063
185304409888 Frigidaire Oven Terminal Block with Hardware
19WCI K005025704
20WCI 3201631
21BODY-OVEN
22WCI 3201632
23316067902 Frigidaire Oven Rack
24WCI 3205539
25GRILLE, BROILER
26WIRE, COVER
27WCI 3051602
28WCI 3051511
29316116400 Frigidaire Oven Light Socket
30316538904 Frigidaire Oven Lamp Light
315304524341 Frigidaire Lens
32RETAINER-LENS
32AANTI-TIP KIT, (NON-ILLUSTRATED)
32BWCI 5300009126
33WCI 3016281
34WCI 5303207446
35BRACKET, VENT TUBE
36WCI 5303207389
37GASKET, OVEN VENT TUBE
