RS677PXYQ0 03 – CONTROL PANEL

Products

Position	Product
1	End Cap (R.H.)
1	End Cap Black (Right Hand)
1	End Cap Black (Left Hand)
1	End Cap (L.H.)
2	Bracket, Control
3	Rail, Top
4	Trim, Center (White)
4	Trim, Center (Black)
5	Trim, Vent Door (Brite Aluminum, R.H.)
5	End Trim, Vent (Left Side)
5	End Trim, Vent (Right Side)
5	Trim, Vent Door (Brite Aluminum, L.H.)
6	Door, Vent (Black)
6	Door, Vent (Brushed Aluminum)
7	Trim, Bottom
7	Screw, 10-32 x 1/2
8	Shield, Air
9	Panel, Control (Black)
9	Panel, Control (White)
10	Control, Electronic (Black)
10	Control, Electronic (White)
11	Shield, Control
12	WP488729 Whirlpool Refrigerator Door Screw
12	488946 Whirlpool Air Conditioner Clamp
13	Shield, Heat
13	Screw (2)
14	Trim, End Cap (Black)
14	Trim, End Cap (White)
15	Switch, Rocker
15	Switch, Rocker (White)
16	Seal, Air Duct
