RT140LCD2 02 – DOOR PARTS

Products

Position	Product
*16889	WCI G89643
1	GASKET-FREEZER
2	GASKET-REFRIGERATOR
3	PANEL-INNER
4	RACK-REFR DOOR (2)
5	5308000716 Frigidaire Refrigerator Dish
6	WCI G161776-33
7	RACK-FREEZER DOOR
8A	5304455651 Frigidaire Refrigerator Screw
8	WCI G180230-01
9	WCI G169332-11
10	FREEZER DOOR-ALMOND
11A	TAPE-FRAME MOUNTING (NON-ILLUSTRATED)
11	FRAME-NAMEPLATE
12	WCI G177218-02
13	BEARING, HINGE (3)
14	WCI G162977-11
15	REFR DOOR-ALMOND
16	WCI G175810
17	WCI G175666-09
18	WCI G187329-01
19	END-HANDLE TOP
20	WCI G185566
