RT150MCD0 04 – SYSTEM AND AUTOMATIC DEFROST PARTS

Written by

Products

Position	Product
*34382	WCI 3916557
1	WCI 5303001341
2	BRACKET-MTG (4)
3A	WASHER, EXT TOOTH LOCK, NO. 10 (NON-ILLUSTRATED)
3	5308000039 Frigidaire Refrigerator Screw
4	5303001199 Frigidaire Refrigerator Wiring Harness Clamp
5	5304455651 Frigidaire Refrigerator Screw
6	5303305677 Frigidaire Replacement Filter Dryer Filters
7	WCI 3206126
8	218513300 Frigidaire Refrigerator Compressor Mount Grommet
9	WASHER-COMPR MTG
10	CLIP – COMPRESSOR MTG
11	PAN-DEFROST-ORIG COMPRESSOR
11C	PAN RETAINER KIT, SERVICE
11A	PAN-DEFROST DRAIN, ORIG/SVCE COMPR
11B	5303307583 Frigidaire Refrigerator P1 Pad Noise Reduction
12	Nut,lock `1/4-20 ,drain pan mtg
13	WCI 530186043
14	WCI 3200718
15	WCI 3200716
16	WCI 5303209254
17	WCI 5303211232
18	CORD-ELECTRIC POWER
19	WCI 5303211497
20	WCI 3200734
21	CLAMP-CONTROL BULB (NON-ILLUSTRATED)
22	WCI 08006983
23	WCI 5303211511
24	5304455650 Frigidaire Refrigerator Screw
25	WCI 5303211504
26	WCI 5303001380
27	WCI 5303211512
