RT153MCD0 02 – DOOR PARTS

Products

Position	Product
1	FREEZER DOOR-ALMD
2A	SUPPORT-DOOR RACK, EXTENDS 1.06“, LH
2	SUPPORT-DOOR RACK, EXTENDS 1.06“, RH
4	WCI 08007123
5	PANEL-INNER DOOR, FRZR
6	5304455651 Frigidaire Refrigerator Screw
7	RACK-DOOR
8	DOOR, DAIRY
9	RACK-DOOR
10	PANEL-INNER DOOR, REFR
11	218730603 Frigidaire Door Gasket
12	REFRIGERATOR DOOR-ALMD
13	BEARING-HINGE
14	WCI G162977-11
15	WCI G169332-11
16	INSULATION-BULK
17	WCI 3206151
17A	WCI 3206150
18	HANDLE-DOOR
19	WCI 3206159
20	SUPPORT-DOOR RACK, EXTENDS .56“, RH
20A	SUPPORT-DOOR RACK, EXTENDS .56“, LH
21	3206166 Frigidaire Refrigerator Freezer Door Shelf Retainer Bar Endcap Rack Support
21	3206165 Frigidaire Bar Endcap Right Hand
22	RACK-DOOR, NARROW
23	RACK-DOOR, SHORT
24	DOOR STOP (2)
24A	SCREW-DOOR STOP (2) (NON-ILLUSTRATED)
25	HANDLE-DOOR
