RT153NCH0 04 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

Position	Product
1	WCI 5303001362
2	5308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
3	EVAPORATOR
4	5303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
5	HEAT EXCHANGER, SUCTION LINE
6A	5308000039 Frigidaire Refrigerator Screw
6	WCI 53080001333
8	RELAY-TL
10	5303006412 Frigidaire Refrigerator Cover Mounting Strap
11	WCI 5303001713
12	CORD-ELECTRIC POWER
13	5308000133 Frigidaire Refrigerator Clamp
14	5303305677 Frigidaire Replacement Filter Dryer Filters
15	WCI 5303001341
16	BRACKET-MTG (4)
17	INSULATION BLOCK, LH
18	WASHER-COMPR MTG
19	CLIP - COMPRESSOR MTG
20	WCI 5308009596
21	COMPRESSOR W/ ELEC
22	218513300 Frigidaire Refrigerator Compressor Mount Grommet
23A	5303307583 Frigidaire Refrigerator P1 Pad Noise Reduction
23	PAN-DEFROST DRAIN, ORIG/SVCE COMPR
24	Nut,lock `1/4-20 ,drain pan mtg
25A	218843801 Frigidaire Refrigerator Screw
25	INSULATION BLOCK, RH
26	INSULATION PLUG, RH
27	WCI 5303018427
28A	HOT TUBE REPAIR KIT-SERVICE
28	STRAP CAPACITOR
29	WCI 5303001197
30	INSULATOR-EVAP, PLASTIC
31	PAN RETAINER KIT, SERVICE
32	WIRING HARNESS, COMPRESSOR,
33	HARNESS-WIRING, CONTROL/DIVIDER,(NON-ILLUSTRATED)
34	5304455651 Frigidaire Refrigerator Screw
34A	WASHER, EXT TOOTH LOCK, NO. 10 (NON-ILLUSTRATED)
35	5303001199 Frigidaire Refrigerator Wiring Harness Clamp
