RT154LCF1 03 – CABINET PARTS

RT154LCF1 03 – CABINET PARTS

Written by

in

RT154LCF1 03 – CABINET PARTS

Products

PositionProduct
*28153WCI 5303006086
*28153PLUG, BUTTON, CABINET LINER (NI)
1WCI 5303001227
1AWCI 5308000107
2G187559 Frigidaire Refrigerator Bushing
3WCI 5303001226
45300158289 Frigidaire Evaporator Fan Motor
5WCI 5303001666
6PLUG-DECORATIVE, ICE MAKER HOLE
7WCI 3001358
7AWCI 5303203044
95308000010 Frigidaire Refrigerator Evaporator Fan Blade
10A218843801 Frigidaire Refrigerator Screw
10RING-FAN ORIFICE
11NUT-SPEED (2)
12DAMPER-FAN COVER
13WCI G000187640
14Nut,push-on
15WCI 5316266315
16WCI 5349007602
17215667501 Frigidaire Refrigerator Ice Tray Primary
18WCI 5308000748
19WCI 5308000759
20TOP PANEL-REFR, W/ SNAP BUSHING
21WCI 5303001380
22CORNER TRIM, COFFEE (4)
23WCI 5308017408
24WCI 3001370
255309918806 Frigidaire Refrigerator Light Switch Door
26WCI 5308003604
27WCI 3916133
27BWCI 5308012258
27AWASHER, NO. 10 STEEL, 7/32 X 7/16 OD (NOT ILLUSTRATED)
28TUBE – DRAIN
29WCI 5303001287
30DEFLECTOR-AIR
31COVER – AIR DEFLECTOR
32316538904 Frigidaire Oven Lamp Light
33215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
33A5304455649 Frigidaire Refrigerator Screw
34SOCKET-LIGHT/LAMP
35TUBE
36WCI 5308015762
36AWCI 5303001260
37WCI 5303001286
38WCI 5308010011
39WCI 5317672202
39B5304455650 Frigidaire Refrigerator Screw
39AWCI G000180037
40COVER-CRISPER PAN
41PAN, CRISPER
42SUPPORT-CRISPER CVR, ADJUSTABLE
43WCI 5317217303
44AWCI 5308003584
44SCREW-LEVELING (4)
45COVER-HOLE, LOWER HINGE
46A241710601 Frigidaire Refrigerator Screw
46HINGE – LOWER DOOR
475303001321 Frigidaire Refrigerator Lower Hinge Pin
48SHIM-LOWER HINGE
49TAPPING PLATE, UPPER HINGE (2) (NOT ILLUSTRATED)
50WASHER, .34 X .62 X .05, NYLON
51TROUGH-DRAIN
52WASHER, .28 X .62 X .19, NYLON
53WCI 5308000184
54BRACKET-CTR HINGE
55SHIM – UPPER HINGE
56BRACKET-UPPER HINGE
57PLUG, COFFEE
58SUPPORT-COIL COVER
59TUBE-RUBBER
