RT154LCF1 04 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

Position	Product
1	WCI 5303001341
2	BRACKET-MTG (4)
3A	WASHER, EXT TOOTH LOCK, NO. 10 (NON-ILLUSTRATED)
3	5308000039 Frigidaire Refrigerator Screw
4	HARNESS-WIRING, CONTROL/DIVIDER,(NON-ILLUSTRATED)
5	WIRING HARNESS, COMPRESSOR,
6	CORD-ELECTRIC POWER
7	WCI 5303001197
8	5304455651 Frigidaire Refrigerator Screw
10	5303001199 Frigidaire Refrigerator Wiring Harness Clamp
11	5303006412 Frigidaire Refrigerator Cover Mounting Strap
12	HEAT EXCHANGER, SUCTION LINE
13	5308000133 Frigidaire Refrigerator Clamp
14	5308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
15	WCI 5303001362
16	INSULATOR-EVAP, PLASTIC
17	EVAPORATOR
18	5303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
19	INSULATION BLOCK, RH
20	INSULATION PLUG, RH
21	INSULATION BLOCK, LH
22	5303305677 Frigidaire Replacement Filter Dryer Filters
22B	218843801 Frigidaire Refrigerator Screw
22A	WCI 3201679
23	WCI 5308009596
24	218513300 Frigidaire Refrigerator Compressor Mount Grommet
25	WASHER-COMPR MTG
26	CLIP - COMPRESSOR MTG
27A	5303307583 Frigidaire Refrigerator P1 Pad Noise Reduction
27	PAN-DEFROST DRAIN, ORIG/SVCE COMPR
28	Nut,lock `1/4-20 ,drain pan mtg
29	PAN RETAINER KIT, SERVICE
30	COMPRESSOR W/ ELEC
31	RELAY-TL
32A	WCI 3202891
32	WCI 5303001713
33A	HOT TUBE REPAIR KIT-SERVICE
34	WCI 5303018427
35	STRAP CAPACITOR
