RT154LCH1 03 – CABINET PARTS

Products

Position	Product
*28153	PLUG, BUTTON, CABINET LINER (NI)
*28153	WCI 5303006086
1A	WCI 5308000107
1	WCI 5303001227
2	G187559 Frigidaire Refrigerator Bushing
3	WCI 5303001226
4	5300158289 Frigidaire Evaporator Fan Motor
5	COVER - HINGE-WHEAT
6	PLUG-DECORATIVE, ICE MAKER HOLE
7A	WCI 5303203044
7	WCI 3001358
9	5308000010 Frigidaire Refrigerator Evaporator Fan Blade
10	RING-FAN ORIFICE
10A	218843801 Frigidaire Refrigerator Screw
11	NUT-SPEED (2)
12	DAMPER-FAN COVER
13	WCI G000187640
14	Nut,push-on
15	WCI 5316266315
16	WCI 5349007602
17	215667501 Frigidaire Refrigerator Ice Tray Primary
18	WCI 5308000748
19	WCI 5308000759
20	TOP PANEL-REFR, W/ SNAP BUSHING
21	WCI 5303001380
22	TRIM-CAB CORNER-WHEAT
23	WCI 5308017408
24	WCI 3001370
25	5309918806 Frigidaire Refrigerator Light Switch Door
26	WCI 5308003604
27B	WCI 5308012258
27	WCI 3916132
27A	WASHER, NO. 10 STEEL, 7/32 X 7/16 OD (NOT ILLUSTRATED)
28	TUBE - DRAIN
29	WCI 5303001287
30	DEFLECTOR-AIR
31	COVER - AIR DEFLECTOR
32	316538904 Frigidaire Oven Lamp Light
33A	5304455649 Frigidaire Refrigerator Screw
33	215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
34	SOCKET-LIGHT/LAMP
35	TUBE
36	WCI 5308015762
36A	WCI 5303001260
37	WCI 5303001286
38	WCI 5308010011
39	WCI 5317672202
39B	5304455650 Frigidaire Refrigerator Screw
39A	WCI G000180037
40	COVER-CRISPER PAN
41	PAN, CRISPER
42	SUPPORT-CRISPER CVR, ADJUSTABLE
43	WCI 5317217303
44A	WCI 5308003584
44	SCREW-LEVELING (4)
45	COVER-HOLE, LOWER HINGE
46A	241710601 Frigidaire Refrigerator Screw
46	HINGE - LOWER DOOR
47	5303001321 Frigidaire Refrigerator Lower Hinge Pin
48	SHIM-LOWER HINGE
49	TAPPING PLATE, UPPER HINGE (2) (NOT ILLUSTRATED)
50	WASHER, .34 X .62 X .05, NYLON
51	TROUGH-DRAIN
52	WASHER, .28 X .62 X .19, NYLON
53	WCI 5308000184
54	BRACKET-CTR HINGE
55	SHIM - UPPER HINGE
56	BRACKET-UPPER HINGE
57	BUTTON-HINGE-WHEAT
58	SUPPORT-COIL COVER
59	TUBE-RUBBER
