RT155MCD1 02 – DOOR PARTS

Products

Position	Product
1	FREEZER DOOR-ALMD
2	SUPPORT-DOOR RACK, EXTENDS 1.06``, RH
2A	SUPPORT-DOOR RACK, EXTENDS 1.06``, LH
4	GASKET-FRZR DOOR, WHITE, MAGNETIC
5	PANEL-INNER DOOR, FRZR
6	5304455651 Frigidaire Refrigerator Screw
7	RACK-DOOR
8	DOOR, DAIRY
9	RACK-DOOR
10	PANEL-INNER DOOR, REFR
11	218730603 Frigidaire Door Gasket
12	REFRIGERATOR DOOR-ALMD
13	BEARING-HINGE
14	WCI G162977-11
15	WCI G169332-11
16	INSULATION-BULK
17A	WCI 3206150
17	WCI 3206151
18	HANDLE-DOOR
19	WCI 3206159
20A	SUPPORT-DOOR RACK, EXTENDS .56``, LH
20	SUPPORT-DOOR RACK, EXTENDS .56``, RH
21	3206165 Frigidaire Bar Endcap Right Hand
21A	3206166 Frigidaire Refrigerator Freezer Door Shelf Retainer Bar Endcap Rack Support
22	RACK-DOOR, NARROW
23	RACK-DOOR, SHORT
24	DOOR STOP (2)
24A	SCREW-DOOR STOP (2) (NON-ILLUSTRATED)
25	HANDLE-DOOR
