RT156HLD3 05 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

Position	Product
*99341	HOT TUBE REPAIR KIT (NON-ILLUSTRATED)
1	5303305677 Frigidaire Replacement Filter Dryer Filters
2	WCI G178225
3	BRACKET-CONDENSER MOUNTING (4)
4	5303006412 Frigidaire Refrigerator Cover Mounting Strap
6	HARNESS, WIRING
7	HARNESS-COMPRESSOR
8	CORD, SERVICE
9	CLIP, COMPRESSOR MOUNTING (4)
10	WASHER, COMPRESSOR MOUNTING (4)
11	218513300 Frigidaire Refrigerator Compressor Mount Grommet
12	DEFROST PAN & NUT
12A	NUT, LOCK
12B	5303307583 Frigidaire Refrigerator P1 Pad Noise Reduction
13	WCI G182225-18
14	COMPRESSOR
15	WCI G188877
16	RETAINER, OVERLOAD
17	5308000039 Frigidaire Refrigerator Screw
18	240396801 Frigidaire Refrigerator Tube Clamp
19	WCI G162822
20	BLOCK, LEFT SIDE
21	BLOCK, EVAPORATOR, RH
22	PLUG, EVAPORATOR INSULATION BLOCK, R H
23	5303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
24	WCI G164563
25	5308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
26	WCI G163389
27	WCI G162432-02
28	INSULATOR
29	WCI G183584
30	CLAMP-CABLE
31	218843801 Frigidaire Refrigerator Screw
32	5303001199 Frigidaire Refrigerator Wiring Harness Clamp
33	WCI G188885-01
34	STRAP-CAPACITOR
35	WCI G167234
