RT163LCH1 03 – CABINET PARTS

Products

Position	Product
*16956	BUTTON, LINER
1	WCI G174747-09
2	WCI G163669
3A	5304500407 Frigidaire Refrigerator Shelf Mounting Grommet
3	5304509705 Frigidaire Refrigerator Grommet
4	WCI G179684-09
5	BRACKET, TOP HINGE
5A	241710601 Frigidaire Refrigerator Screw
6	WCI G103903
7	WCI G183861
8	COVER HINGE, WHEAT
9	NUT, ANCHOR (2)
10	LEG-LEVELING (2)
11	BOTTOM, FC
12	DIVIDER, CENTER
12A	HARNESS, WIRING
13	TOP-REFRIGERATOR
14	SPACER (NON-ILLUSTRATED)
15	HTR, CENTER RAIL
16	WCI 3916132
17	5309918806 Frigidaire Refrigerator Light Switch Door
18	WCI G142220
19	BRACKET, HINGE CENTER
20	WASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET)
21A	SCREW, BRACKET MOUNTING (4)
21	CLAMP, MULLION MOUNTING
21B	WASHER (2)
22	DEFLECTOR AIR
23	WCI G162178
24	316538904 Frigidaire Oven Lamp Light
25	215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
25A	5304455649 Frigidaire Refrigerator Screw
26	TUBE
27	WCI 3200810
27A	WCI G107080
28	WCI G178402-02
29	KNOB
30	SOCKET LIGHT
31A	5304455650 Frigidaire Refrigerator Screw
31	WCI G176722-01
32	LABEL-BOX
33	5303001321 Frigidaire Refrigerator Lower Hinge Pin
34	BRACKET-HINGE
35	SHIM, HINGE
36	WCI G490015-01
37	SUPPORT, CRISPER COVER
38	WCI G490016-03
39	SHELF-SLIDING (3)
40	WCI G166912
41	TUBE, INSULATION (2)
42	WCI G174734
43	WCI G174733
44	215667501 Frigidaire Refrigerator Ice Tray Primary
45	CABINET BASE
