RT163LLH1 04 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

PositionProduct
*16960HOT TUBE REPAIR KIT
*16960HARNESS-COMPRESSOR
*16960HARNESS, WIRING
1WCI G178225
2BRACKET-CONDENSER MOUNTING (4)
2A5308000039 Frigidaire Refrigerator Screw
35303305677 Frigidaire Replacement Filter Dryer Filters
45303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
5WCI G164571
65304455651 Frigidaire Refrigerator Screw
7G187559 Frigidaire Refrigerator Bushing
8WCI G185302
95300158289 Frigidaire Evaporator Fan Motor
10WCI G185303
11RING, FAN ORIFICE
125308000010 Frigidaire Refrigerator Evaporator Fan Blade
13WCI 162663-15
14NUT, DAMPER MOUNTING
15WCI G490076-01
15B5304455650 Frigidaire Refrigerator Screw
15ALABEL-FAN COVER
16DAMPER FAN COVER
17NUT, ORIFICE (2)
18PLUG-BUTTON DECOR
19APLUG-SHORT TEST HOLE (NON-ILLUSTRATED)
19COVER-COIL
20EVAPORATOR
215308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
22APIN PUSH SPOUT (2)
22SPOUT DRAIN TUBE
23HEAT, EXCHANGE
24HEATER, DEFROST
25DEFROST PAN
26NUT, LOCK
26A5303307583 Frigidaire Refrigerator P1 Pad Noise Reduction
27PAN RETAINER KIT-SERVICE
28AWCI G150618-33
28WCI G182225-12
29AWCI G176002
29WCI G185797
30WCI G185792
31STRAP-COVER
31A5303006412 Frigidaire Refrigerator Cover Mounting Strap
32COMPRESSOR WITH ELECTRICALS
33218513300 Frigidaire Refrigerator Compressor Mount Grommet
34WASHER, COMPRESSOR MOUNTING (4)
35CLIP, COMPRESSOR MOUNTING (4)
36PLATE
37CORD, SERVICE
38WCI G184290-01
38ARING, SEAL (NON-ILLUSTRATED)
39TROUGH-DRAIN
40INSULATOR
41APLUG, EVAPORATOR INSULATION BLOCK, R H
41BLOCK, EVAPORATOR, RH
41BBLOCK, LEFT SIDE
42WCI G183584
