RT163NLDA 02 – DOOR PARTS

RT163NLDA 02 – DOOR PARTS

Written by

in

RT163NLDA 02 – DOOR PARTS

Products

PositionProduct
*37899WCI 5308011745
1FREEZER DOOR – ALMOND
2PLUG-BUTTON, ALMOND, HINGE BRG HOLE
3BEARING-HINGE
4WCI 3206159
5AINSULATION-BULK (NON-ILLUSTRATED)
5REFRIGERATOR DOOR – ALMOND
7PLUG-BUTTON, ALMOND, HANDLE/DR STOP
8WCI G176988-01
9218730603 Frigidaire Door Gasket
10WCI 5303001399
11A218843801 Frigidaire Refrigerator Screw
11WCI G176904-01
13WCI 5317689101
14WCI 5317689201
16WCI G176911-01
17WCI 5317722001
18WCI 5317722101
19WCI 5317722201
20RACK-DOOR, (2)
21HANDLE-DOOR
22HANDLE-DOOR
