RT175GLF3 05 – SYSTEM AND AUTOMATIC DEFROST PARTS

RT175GLF3 05 – SYSTEM AND AUTOMATIC DEFROST PARTS

Written by

in

RT175GLF3 05 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

PositionProduct
15303305677 Frigidaire Replacement Filter Dryer Filters
2WCI G184719
3BRACKET-CONDENSER MOUNTING (4)
45308000039 Frigidaire Refrigerator Screw
55303001147 Frigidaire Refrigerator Plug-Harness Hole
6215456100 Frigidaire Refrigerator Water Inlet Tube
6AWCI G154156
7CORD, SERVICE
7AHARNESS COMPR
8WCI G183584
9WCI C620106
10SCREW – 1/4-20 (3) COMP. MTG.
11SLEEVE COMP MTG (3)
12218513300 Frigidaire Refrigerator Compressor Mount Grommet
13WCI G182225-11
14WCI G187874
15RETAINER, OVERLOAD
175303006412 Frigidaire Refrigerator Cover Mounting Strap
18DEFROST PLATE (NON-ILLUSTRATED)
19BRACKET, DRAIN TUBE
20HOT TUBE REPAIR KIT (NON-ILLUSTRATED)
