RT175MCD1 02 – DOOR PARTS

Products

Position	Product
*31237	INSULATION-BULK (NON-ILLUSTRATED)
1	FREEZER DOOR-ALMD
2	PLUG-BUTTON, ALMOND, HINGE BRG HOLE
3	BEARING-HINGE
4	WCI 3206159
5	WCI 5308000255
8	PLUG-BUTTON, ALMOND, HANDLE/DR STOP
9	WCI 5308011745
10	GASKET-FRZR DOOR, WHITE, MAGNETIC
11	WCI 3206188
12	RACK-DOOR
13	SUPPORT-DOOR RACK, EXTENDS 1.06“, RH
13A	SUPPORT-DOOR RACK, EXTENDS 1.06“, LH
15	RACK-DOOR, SHORT, NARROW, (2)
16	DOOR, DAIRY
17	HANDLE-DOOR
18	218843801 Frigidaire Refrigerator Screw
19	218730603 Frigidaire Door Gasket
20	RACK-DOOR
21	WCI 3206192
22	REFRIGERATOR DOOR-ALMD
23	HANDLE-DOOR
24	RACK-DOOR, NARROW
25	WCI 3206189
26A	WCI 3206151
26	WCI 3206150
27	WCI 3206190
28A	3206166 Frigidaire Refrigerator Freezer Door Shelf Retainer Bar Endcap Rack Support
28	3206165 Frigidaire Bar Endcap Right Hand
