RT175MCD1 03 – CABINET PARTSadmin2025-04-26T10:26:55+00:00RT175MCD1 03 – CABINET PARTS
Products
| Position | Product |
|---|
| *31250 | TAPPING PLATE, UPPER HINGE (2) (NOT ILLUSTRATED) |
| *31250 | PLUG, BUTTON, CABINET LINER (NI) |
| 1 | WCI 5303001227 |
| 2 | 5300158289 Frigidaire Evaporator Fan Motor |
| 3A | 5304455651 Frigidaire Refrigerator Screw |
| 3 | WCI 5308000107 |
| 4 | WCI 5303001226 |
| 5A | 218843801 Frigidaire Refrigerator Screw |
| 5 | RING-FAN ORIFICE |
| 6 | G187559 Frigidaire Refrigerator Bushing |
| 7 | 5308000010 Frigidaire Refrigerator Evaporator Fan Blade |
| 8 | WCI 3206110 |
| 9 | Nut,push-on |
| 10 | WCI 3206109 |
| 11 | FAN COVER |
| 11A | 5304455650 Frigidaire Refrigerator Screw |
| 12 | WCI 3206105 |
| 13 | WCI 3206100 |
| 14 | WASHER, .34 X .62 X .05, NYLON |
| 15 | TRIM-CABINET CORNER, ALMOND |
| 16 | WCI 5308000186 |
| 17 | WCI 5308000184 |
| 18 | BRACKET-CTR HINGE |
| 19 | SCREW - MULLION (2) |
| 20 | WCI 3204206 |
| 21 | COVER - AIR DEFLECTOR |
| 22 | 5303001321 Frigidaire Refrigerator Lower Hinge Pin |
| 23 | WCI 3206136 |
| 24 | 241710601 Frigidaire Refrigerator Screw |
| 25 | 5303208309 Frigidaire Refrigerator Plug Hole |
| 26 | WCI 3206135 |
| 27 | WCI 3206237 |
| 28 | TUBE-DEFROST DRAIN |
| 28A | WCI 5300187009 |
| 29 | BOLT-ROLLER ADJ, (2) (NON-ILLUSTRATED) |
| 30 | PLUG-BUTTON, ALMOND, UPR HINGE HOLES |
| 31 | WCI 5308000056 |
| 32 | WCI 5303001361 |
| 33 | TUBE-RUBBER |
| 34 | WCI 3206119 |
| 34A | NUT-SPEED (2) |
| 35 | SUPPORT-COIL COVER |
| 36 | PLUG-BUTTON |
| 37 | WCI 3206146 |
| 38 | SHIM - UPPER HINGE |
| 39 | WCI 5300188673 |
| 39B | WCI 5308009790 |
| 39C | 5304500008 Frigidaire Oven Screw |
| 39A | WCI 5308009760 |
| 40 | SEAL RING-DRAIN TUBE |
| 41 | WCI 5308011326 |
