RT175MCF0 04 – SHELVES AND SUPPORTS

RT175MCF0 04 – SHELVES AND SUPPORTS

Written by

in

RT175MCF0 04 – SHELVES AND SUPPORTS

Products

PositionProduct
1WCI 3206187
2ASUPPORT-SHELF (2) (NON-ILLUSTRATED)
2WCI 3001570
2EWCI G186773
2CWCI 3001562
2BSCREW-SUPPORT (2)
2D5304455852 Frigidaire Refrigerator Screw
3WCI 3206120
4SHELF-SLIDING, REFR, (3)
5FRONT-CRISPER PAN-LH
6WCI 3206183
7PAN – CRISPER
8SPACER (NON-ILLUSTRATED)
9WASHER (2)
10WCI 3206130
10A5304455650 Frigidaire Refrigerator Screw
11KNOB-TEMP CONTROL
12WCI 3206129
13SCREW – MULLION (2)
14AWCI G107080
14CONTROL-TEMPERATURE
15WCI 3018891
16215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
16A5304455649 Frigidaire Refrigerator Screw
17218906802 Frigidaire Light Lamp Socket
18316538904 Frigidaire Oven Lamp Light
195309918806 Frigidaire Refrigerator Light Switch Door
20WCI 3206185
20ASCREW (5)
21WCI 3206182
22CLAMP, MULLION MOUNTING
23WCI 3206186
23B3205266 Frigidaire Refrigerator Edge Protector
23AWCI 3018900
24WCI 3206124
